Law Enforcement Body Camera Docking Station 20 Ports With Management System

video play

Large Image :  Law Enforcement Body Camera Docking Station 20 Ports With Management System

Product Details:
Place of Origin: Shenzhen, China
Brand Name: Ishoop
Certification: CE
Model Number: SOP-A2
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: Negotiable
Packaging Details: Neutral Carton Packing
Delivery Time: 1-2 working days
Payment Terms: T/T, Western Union, MoneyGram, Paypal
Supply Ability: 2000pcs/per month
Detailed Product Description
Function: Multi-cameras Uploading And Charging Maximum Number Of Connections: 20ports
Voltage Of Each Port: 5 V Maximum Current Of Each Port: 2.0 A, Adaptive According To The Connected Device
Maximum Input Power: 500W Warranty: One Year
Main Board: B75 Main Board Hard Disk: 4T Seagate Hard Disk ST4000DX004 7200rpm, 6Gb/s
High Light:

universal docking station


docking station for camera

Law Enforcement Body Camera Docking Station 20 Ports With Management System


Specification-A2-DOCK STATION-20Units.pdf


Police Camera Docking Station is the latest charging and data uploading device, which can

connect up to 20 cameras, via USB2.0 port, compatible with the most of police body cameras

in the market. In addition to total power of docking reach 120 W, each port can provide up to

2.0A of self-adaption current, according to the connected devices. Users only need an office computer, without cumbersome wiring. It features multi-device data collection and charging.

  • All-metal structure, it is durable and tough.
  • Fully compatible with USB1.1 and USB2.0, support hot-swappable, compatible with most of body worn cameras.
  • With dual protection on the output, it can protect your connected device from overloading, support overload voltage and instantaneous current protection; each port provides up to 2.0A current.
  • Enforcement recorder clip can be fixed at eight slots, which are neatly arranged.
  • L-shaped USB connector, handsome and reliable.
  • Docking has four pads can be stably placed on any flat surface.
  • Docking station has six vents, internal motherboard is equipped with a fan. To prevent from downtime due to over heat.
  • Equipped with a switch, which can be directly turn off eight USB power.
  • With a wall bracket can be mounted onto a vertical wall.
  • Support Win7, Window Vista, Windows XP Professional / Home Edition Window98 / ME / 2000 Professional / and others.



Port 20 ports
Main board B75 main board
CPU Intel I3 3240 Dual core four thread (LGA1155/3.3GHZ/3M)
Memory 4G Kingston DDR3 1333 Memory
Hard disk 4T Seagate hard disk ST4000DX004 7200rpm, 6Gb/s,
Source 500 W
System Disk 60G Solid disk
Network Card Kilomega net card
Disk Array Hard disk can extend to 4T*6 (with array)
Display 19 inch LCD touch screen, Resolution 1920*1080
Horn Loudspeaker
Software System WIN 7 32/64 bit system
Utility Software Electronic evidence management system
Database SQC server express 2008
Wire Material Data Wire 5P USB data line
USB Interface USB 3.0 HUB,transmission rate≥400M/min
Network Wire RJ45 network wire
Power Wire 1.8M standard power line
Power Input Power 220V AC
Accessory User Manual User handbook CD
Software Encryption Software encryption dog HASP PRO(sub lock)
Fuse 220V 10A fuse
New Function System recovery

Using 60G solid hard disk to do system disk,

to make system recovery function,

when the operating system or software abnormal,

it can be restored to the factory state.

Auto switch machine

To protect the data station, the machine can shut down

And turn on automatically at a regular time everyday

or every week by your setting.

Screen protect

The screen saver function, the screen will be off automatically

if the user don’t operate the machine more than 10mins;

touch screen, the machine will wake up.
