H.264 IP66 HD 1080P Mini Body Camera Photography Sound Record

H.264 IP66 HD 1080P Mini Body Camera Photography Sound Record

H.264 HD 1080P Mini Body Camera

IP66 HD 1080P Mini Body Camera

IP66 1080P Body Camera

Place of Origin:


Brand Name:




Model Number:


Contact Us

Request A Quote
Product Details
Video Format:
Ir Distance:
10 Meters Face Detection
Wireless Camera
Product Description

H.264 IP66 HD 1080P Mini Body Camera Photography Sound Record


Photograph Security Body Camera Sound Record HD 1080P Mini Vedio Camera

Specification of body police camera-SOP-04-GE.pdf


Product detail parameters of Police Security Body Camera:

night vision able to see the facial appearance of humans clearly within 10m in complete darkness.
Double-filter switcher no color cast in the daytime, clearer in the nighttime.
ID cameras Unable to look up or delete the data of recording files, unless authorized.
GPS function build-in
Wifi function build-in
Function of character superimposition all videos and pictures will be attached with time, device ID, police ID and other information, they are able to be edited or rearranged, for providing more effective legal evidence.
Super-long filename file names of all video files include device ID, time, police ID and other information, convenient for data archiving and retrieving.
Full HD Full HD 1080P video recording
Three main functions namely video recording, photo-shooting and sound recording.
Able to play back the audio record, video record, and picture Video data will be partitioned and saved operation, automatically, avoiding the data loss caused by faulty
Three kinds of operation prompts namely vibration, LED light and sound.
2.0 Inch LCD display
Frame Rate 30f/s-60f/s
Video Bitrate 2.5Mbit/S
Video MP4 H.264/H.265 compressed
Resolution 2560*1080,1296P30,1080P30,720P60,720P30, 480P
Photo JPEG 7696*4329, 4608*3456
Wide angle 140°
Illumination requirement day and night (auxiliary IR)
Battery capacity 3200mAh
Memory capacity 16G(32G/64G/128G)
hi-speed communication USB2. 0
Contour dimension 77*57*26mm
Weight 143g
Operating temperature -40-60℃
Working relative humidity 40%-80%
Storage temperature -20-55℃
Storage relative humidity ≤93% (40℃)
Waterproof level IP67



*Power On/ Off:Press the power switch button of law-enforcement recorder for 3 seconds, the camera will be turned on. If no operation is conducted in 3 minutes after it is turned on, the camera will be powered off automatically.

1 .  White Light

2 .  IR Light

3 .  Metal Clip

4 . Confirm/Menu

5 .  Return/Playback

6 . zoom+/Up

7 .  zoom-/Down

8 .  Reset

9 .  Mini USB

10 .  Power on/off

11  .   SOS

12  .   Video record

13  .  Photograph

14 .  Sound Record

15 .  Night Vision

16 .  Power indicator

17 .  Work indicator

18 .  4-pin port(USB)
