Front Big Button Ambarella 5MP CMOS Mini Police Body Camera 1296P Night Vision

Front Big Button Ambarella 5MP CMOS Mini Police Body Camera 1296P Night Vision

5MP CMOS Portable Body Camera

Ambarella A7LA50 Portable Body Camera

1296P IP67 Waterproof Body Camera

Place of Origin:


Brand Name:




Model Number:


Contact Us

Request A Quote
Product Details
Portable Body Camera
Video Format:
18 Months
Ambarella A7LA50
Storage Capacity:
Product Description

Front Big Button Ambarella 5MP CMOS Mini Police Body Camera 1296P Night Vision

Specification of body police camera-SOP-09.pdf


Discription Of Body Camera:


1, The body worn camera SOP-09 is a law enforcement recorder independently designed and developed

according to the requirements of law enforcement agencies.


2, Using the world's leading two-color mold casting process, IP67 top protection level, 36 million real pixels,

standby time more than 20 days, up to 128G memory, continuous video recording time of more than 10 hours.


3, This product is independently developed and produced by our company.

 It has the advantages of powerful functions, simple operation, friendly interface, practical and durable.


Features Of Body Camera:

  • The equipment integrates digital camera, video, and recording functions, with permanent police identification, and each equipment body has a separate unique product serial number.
  • Portable dedicated shoulder-hanging clip, wear more firmly, the machine can adjust the shooting position in all directions.
  • Three-proof level: the equipment's waterproof and dustproof level is IP67, shockproof, and can withstand a free fall of 2 meters on the concrete floor when it is turned on. It will not affect the normal operation of the equipment. It is suitable for normal use in an environment of -40℃ to 60℃.

Specification Of Body Camera:

Main Chipset Ambarella A7L50
Sensor 5MP CMOS sensor
Lens 140 degree, wide angel F2.0
Video Resolution 2560x1080(30 FPS)/2304X1296(30 FPS)/1296 1920x1080P(30FPS)/1280x720(30FPS)/848x480(30FPS)
Video Format H.264 MPEG4
Fast forward 2X, 4X, 8X,16X, 32X, 64X
Audio High Quality Build-in Microphone.
Audio Format AAC2/MP3
Water Mark User ID, Time and date Stamp Embedded into Video.
Camera 36 Megapixel Camera option with optional burst shot(5/10/15/20/25 photos)
Camera Format 36M, 16M, 12M, 8M, 5M
Snap Shot Capture Photos During Video Recording
Shutter time 1/1000-1/2 seconds
Infrared illumination for night Not less than 4.5 m in total darkness
Car Mode Support
Loop Recording Loop recording to be switched on / off in the settings
Cycle Recording Support
Storage Capacity 16G/32G/64G/128G
Storage Level Visual Indicator
Record Led Red
One Button Recording Support One Button Record
Activation prompt Audible, Visual, and Tactile Vibration Confirm Activation of Record
IR Light 2 IR Lights
LCD Screen 2 inch TFT-LCD High-Resolution Color Display
Audio Playback Yes
Video Transfer USB 2.0
Recording Angle Wide Angle 140 degrees
focus range Standard installation of at least 1.5 m to infinity
Night Vision Up to 10 Meters with Visible Face Detection
Waterproof IP67
Clip High Quality Metal Clip with 360 degrees Rotation
Wifi Option
GPS Option, Internal GPS, GPS player to show the route of video;
Type Built-in 3200mAH Lithium
Charging Time 180 minutes
Continuous Recording 8 Hours(LCD OFF), if power bank is connected, then no limitation
Low Battery Warning Beep Alert
Unique ID number/unit Include 5 digit device ID and 6 digit police ID
Language English/Chinese/Russian


This product has been widely used in traffic police, public security, public security, urban management, prisons, border defense, military, transportation, mines, factories, ports and other institutions across the country. The products are generally recognized and highly praised.
