USB2.0 IP67 5MP CMOS Waterproof Body Camera Ambarella H22

USB2.0 IP67 5MP CMOS Waterproof Body Camera Ambarella H22
USB2.0 IP67 5MP CMOS Waterproof Body Camera Ambarella H22
video play

Large Image :  USB2.0 IP67 5MP CMOS Waterproof Body Camera Ambarella H22

Product Details:
Place of Origin: Shenzhen
Brand Name: SHOOP
Certification: CE
Model Number: SOP-04
Payment & Shipping Terms:
Minimum Order Quantity: 1pc
Price: Negotiable
Packaging Details: 1 piece in a gift box, 20pcs in one carton, carton size is 45*36*33.5cm
Delivery Time: 3-5 working days
Payment Terms: Western Union, T/T
Supply Ability: 5000 pcs/per month
Detailed Product Description
Product Name: Body Worn Video Camera Waterproof: IP67
Sensor: 5MP CMOS Chip: Ambarella H22
Wireless: WIFI (optional) Drop Proof: 2M
Lens: 140 Demesion: 77 Mm *57 Mm *26mm
High Light:

5MP CMOS Waterproof Body Camera

,

USB2.0 IP67 Waterproof Body Camera

,

Police Video Camera Ambarella H22

Waterproof IP67 Body Worn Video Camera With 5MP CMOS Sensor



Adopt a new design, small size, light weight, large screen, clear playback picture quality. The enclosure protection grade is IP67 standard. It is dustproof to level 6, waterproof level to level 7, and has a 2-meter drop resistance function. The functional design adopts one-button operation design and corresponding indicator light prompts, and one-button access to video, photograph, audio, playback, intercom and other functions.
To
Equipped with a 5MPCMOS sensor 30 million pixel camera, internal and external cameras are 140 degrees, large aperture, optional external camera. Bring a new high-definition field of vision, without distortion of the image. Shows richer details, automatically adjusts white balance and sensitivity, clear images, and provides a reliable basis for research and judgment. High-speed continuous shooting function: Quickly capture every moment, and capture clear, complete and undamaged important pictures in every intense and sporty scene, which fully meets the requirements for grabbing and retaining important evidence.



  • Falling height: It can withstand a free fall on the concrete floor over 3.0 meters, and the machine works normally.
  • Camera: It adopts 5-inch CMOS image sensor, supports 2-32 times speed video playback, and can realize macro or remote shooting. The actual effective number of pixels is 30 million, and the horizontal field of view is 140° wide-angle imaging to ensure that the captured picture is clear without any omissions or dead angles;
  • Video recording function: The resolution meets the requirements of 2560x1440(30FPS)/2304x1296(30FPS)/1920x1440(30FPS)/1920x1080P(30FPS)/1280x720(30FPS)/848x480(30FPS) six levels adjustable, you can choose the resolution according to your actual needs, the maximum Save memory space to a great extent, ensure clear and smooth picture quality. When the machine is off, it can be turned on with one key and enter the recording state (recording when turning on);



Main Chipset Ambarella H22
VIDEO ENCRYPTION AES256(OPTION)
Sensor IMX335, 5MP CMOS sensor
Lens 140 degree, wide angel F2.0
Video Resolution 2560x1440(30FPS)/2304x1296(30FPS)/1920x1440(30FPS)/1920x1080P(30FPS)/1280x720(30FPS)/848x480(30FPS)
Video Format H.264 MPEG4/H.265 MPEG4
Fast forward 2X, 4X, 8X,16X, 32X, 64X
REW 2X, 4X, 8X, 16X, 32X, 64X
Audio High Quality Build-in Microphone.
Audio Format AAC2/MP3
Water Mark User ID, Time and date Stamp Embedded into Video.
Photo Burst 5/10/15/20/25 photos
Self timer capture 3 Sec/5 Sec/10 Sec/30 Sec/60 Sec



Camera Format

30M(6400x4800 4:3), 16M(4608x3456 4:3), 12M(4000x3000 4:3), 8M(3840x2160 4:3), 5M(2560x1920

4:3), 3M(2048x1536 4:3), 2M(1920x1080 16:9)

Snap Shot Capture Photos During Video Recording
Shutter time 1/1000-1/2 seconds
Infrared illumination for night vision



Not less than 4.5 m in total darkness

Loop Recording Loop recording to be switched on / off in the settings
Storage Capacity 16G/32G/64G/128G
Storage Level Visual Indicator
Record Led Red
One Button Recording Support One Button Record
Activation prompt Audible, Visual, and Tactile Vibration Confirm Activation of Record
IR Light 2 IR Lights
VIDEO/IMAGE REVIEW
LCD Screen 2 inch TFT-LCD High-Resolution Color Display
Audio Playback Yes
Video Transfer USB 2.0
CAMERA
Recording Angle Wide Angle 140 degrees
Focus range Standard installation of at least 1.5 m to infinity
Night Vision Up to 10 Meters with Visible Face Detection
Waterproof IP67
Clip High Quality Metal Clip with 360 degrees Rotation
Wifi Option
GPS Option, Internal GPS, GPS player to show the route of video;
BATTERY
Type Built-in 3200mAH Lithium
Charging Time 180 minutes
Continuous Recording

No less than 10hours for 1080p30(H.264), power consumption 270mAh(1080p30, LCD off);
