Wifi Body Worn Camera
Product Details:
Compression: H.264 MPEG4/H.265 MPEG4
Main Chipset: Ambarella H22
Video Resolution: 1080P30, 720P30
Photo Size: 4M/8M/12M/16M/30M/40M
Pre_recording: 5sec/10sec/15sec/20sec/30sec/60sec/2Minutes
Post_recording: 5sec/10sec/15sec/20sec/30sec/60sec/2Minutes
Battery: 3400mAh
Memory: 32G/64G/128G/256G
Sensor: OS05A20
Compression: H.264 MPEG4/H.265 MPEG4
Main Chipset: Ambarella H22
Video Resolution: 1080P30, 720P30
Photo Size: 4M/8M/12M/16M/30M/40M
Pre_recording: 5sec/10sec/15sec/20sec/30sec/60sec/2Minutes
Post_recording: 5sec/10sec/15sec/20sec/30sec/60sec/2Minutes
Battery: 3400mAh
Memory: 32G/64G/128G/256G
Sensor: OS05A20
- Product Description
WiFi Body Worn Camera: Professional Law Enforcement Recording Solution
Are you searching for a reliable WiFi Body Worn Camera that combines cutting-edge technology with unmatched durability? See no encourage than ISHOOP's progressed body-worn recording arrangement. Our item highlights the effective Ambarella H22 chipset, conveying crystal-clear 1440P video determination for proficient law requirement applications. With over 10 a long time of fabricating mastery, we get it what advanced police divisions require.
Specification
| RECORDING | Main Chipset | Ambarella H22 |
| Sensor | OS05A20 | |
| Lens | 140 degree, wide angel F2.0 | |
| Video Resolution | 2560X1440 25P / 1920X1080 50P / 1920X1080 25P / 1280X720 50P / 1280X720 25P / 848X480 25P | |
| Video Format | H.264 MP4 / H.265 MP4 | |
| Fast forward | 2X, 4X, 8X, 16X, 32X, 64X | |
| REW | 2X, 4X, 8X, 16X, 32X, 64X | |
| Audio | High Quality Build-in Microphone | |
| Audio Format | AAC | |
| Water Mark | User ID, Time and date Stamp Embedded into Video | |
| Photo Burst | 2/3/5/10/15/20/30 pcs | |
| Selfie | 3sec / 5sec / 10sec | |
| Photo size | 4M / 8M / 12M / 16M / 30M / 40M | |
| Photo Format | JPG | |
| Snap Shot | Capture Photos During Video Recording | |
| Loop Record | Loop record to be switched on / off in the settings | |
| Pre Record | 5sec / 10sec / 15sec / 20sec / 30sec / 60sec / 2Minutes | |
| Post Record | 5sec / 10sec / 15sec / 20sec / 30sec / 60sec / 2Minutes | |
| Storage Capacity | 32G / 64G / 128G | |
| Storage Level | Visual Indicator | |
| Record Led | Red | |
| One Button Recording | Support One Button Record | |
| Activation prompt | Audible, Visual, and Tactile Vibration Confirm Activation of Record | |
| IR Light | 2 IR Lights | |
| VIDEO/IMAGE REVIEW | LCD Screen | 2 inch TFT-LCD High-Resolution Color Display |
| Audio Playback | Yes | |
| Video Transfer | USB 2.0 | |
| CAMERA | Recording Angle | Wide Angle 140 degrees |
| Night Vision | Up to 10 Meters with Visible Face Detection | |
| Waterproof | IP67 | |
| Clip | High Quality Metal Clip with 360 degrees Rotation | |
| Wi-Fi | 2.4G & 5G, AP/STA/P2P, Wi-Fi channel can be set by cam manager | |
| GPS | Internal GPS, GPS player to show the route of video | |
| BATTERY | Recording Time | 1080P Up to 12 Hours; 480P Up to 15 Hours (GPS and Wi-Fi on at 480P30: 12 hours and 30 minutes) |
| Recording and Streaming Time | 7 to 8 hours | |
| Standby Time | 100+ hours | |
| Charging Time | 4 hours | |
| OTHERS | Unique ID number/unit | Include 6 digit device ID and 6 digit police ID |
| Language | English / Chinese | |
| Password Protection | To set an administrator password on the PC management software to allow deletion from PC, and modify the password in the PC management software | |
| Motion Detector | The ability to adjust the recording if the motion | |
| Sound notification | Beep when starting video or stopping video, or beep sound when opening the menu; beep volume is adjustable in the menu | |
| Dimension | 77 mm * 57 mm * 26 mm (2.91” * 1.83” * 0.93”) | |
| Pre-recording | 30 seconds to 1 minute (varies from resolution settings) | |
| Post-recording | 30 seconds to 1 minute (varies from resolution settings) | |
| The ability to turn off the display while recording | The display can be switched on or off during recording | |
| Falling from height | Resistance to fall from a height of not less than 200 cm | |
| Wifi | Support STA mode | |
| Streaming Resolution | 1920x1080 / 1280x720 / 848x480 / 432x240 | |
| Streaming Frame Rate | 5FPS / 10FPS / 15FPS / 20FPS / 25FPS / 30FPS | |
| Streaming Bitrate | 300 Kbps / 500 Kbps / 1000 Kbps / 2000 Kbps / 3000 Kbps / 4000 Kbps / 5000 Kbps | |
| Live stream Monitor Platform | Support h265 streaming Multi-cameras video Monitor, Position display, intercom, PTT, and etc | |
| Cam manager | Wi-Fi SSID/Password, end point IP, device ID etc, include general settings | |
| PTT | Support talk from camera with the control room (officers) | |
| SOS | Support send message to control room | |
| Video Stamp | Content support User ID / Device ID / Date / Time / Geo-tags / Logo | |
| Security Features (Optional) | File Encryption | AES256 encryption during writing files to memory card; AES256 encryption RTSP Video/audio/Text streaming data |
| Network Security | Http & Https Server | |
| Wi-Fi Security | Dynamic Pin Code authentification | |
| USB Command & JSON command | All camera settings available under mass storage mode; All camera settings available under USB simple mode; USB heart beat available; Control over LED/buzzer available under mass storage mode; Ambarella driver free even while USB encryption activated; Support driver free connection to computer |

Advanced Innovation That Makes a Difference
Your law authorization operations request gear that performs faultlessly beneath weight. Our body camera coordinating modern highlights that set it separated from standard recording devices.
The Ambarella H22 chipset conveys smooth 1440P30 video, whereas AES256 military-grade encryption ensures recordings from unauthorized get to, guaranteeing high-quality, secure prove capture in all conditions.
Wireless Connectivity and Live Streaming
Modern policing requires real-time communication capabilities. Your WiFi Body Worn Camera connects seamlessly to wireless networks, enabling instant data transfer and live streaming functionality.
Live video feeds provide situational awareness, GPS tracks precise locations, and the SOS feature ensures officer safety, improving response coordination in emergencies.
Exceptional Battery Performance and Storage
The 3400mAh battery underpins 10+ hours of recording, extendable with outside control. Select 32–256GB capacity and H.264/H.265 groups for productive, high-quality video.
Pre-recording and post-recording highlights capture pivotal minutes you might something else miss. Movable settings extend from 5 seconds to 2 minutes, guaranteeing total prove collection.
Rugged Plan for Real-World Use
Cameras withstand drops, impacts, and climate, assembly IP67 waterproof and IK09 affect guidelines to guarantee solid prove collection in all law requirement conditions.
The compact, lightweight plan guarantees comfortable all-day wear. Officers appreciate hardware that doesn't meddled with their portability or consolation amid amplified shifts.
Flexible Applications Across Departments
Different law enforcement agencies have unique requirements. Public security officers need cameras with an authoritative presence that deters criminal activity. Municipal enforcement teams prefer more discreet designs that facilitate cooperative interactions.
Our WiFi Body Worn Camera adapts to these varying needs through thoughtful design elements. The professional appearance maintains credibility while remaining approachable for community policing initiatives.
Traffic enforcement, investigations, court security, and patrol operations all benefit from consistent, high-quality evidence collection. One camera system serves multiple departmental functions effectively.

Photo Capabilities and Evidence Management
Beyond video recording, your camera captures high-resolution photos up to 40 megapixels. Crime scenes, evidence documentation, and incident reports benefit from this exceptional image quality.
The OS05A20 sensor captures clear images in all lighting. Automatic timestamps, GPS, and case numbers simplify file management, supporting accurate documentation and efficient evidence handling.
Professional Support and Service
ISHOOP stands behind every product with comprehensive support services. Our experienced group gives specialized help, preparing assets, and progressing support support.
Installation direction guarantees your group maximizes camera capabilities from day one. Computer program overhauls keep your gear current with most recent highlights and security enhancements.
We offer customization alternatives for particular departmental necessities. OEM and ODM administrations make custom fitted arrangements that coordinate your interesting operational needs.
Investment in Officer Safety and Accountability
Your WiFi Body Worn Camera investment extends beyond equipment purchase. These devices protect officers through documented evidence while promoting transparency and accountability.
Reduced complaints, faster case resolutions, and improved community relations represent measurable returns on investment. Officers gain confidence knowing their actions are accurately documented.
Ready to enhance your department's capabilities with professional-grade recording equipment? Contact our team at sales@ishoop.com.cn to discuss your specific requirements and explore available options.
Our commitment to quality, innovation, and customer satisfaction has earned trust from law enforcement agencies across more than 30 countries worldwide.
