Real Time Body Camera with Advanced Streaming Technology
In today's demanding law enforcement environment, you need equipment that keeps pace with real-world challenges. The Real Time Body Camera from ISHOOP delivers professional-grade performance, combining cutting-edge technology with reliable field operation. This gadget changes how officers archive occurrences and keep up responsibility. Built by Shenzhen Kexin Innovation Co., Ltd. with over 10 a long time of advanced imaging ability, it speaks to the apex of police camera innovation.
Specifications
| Size/weight/button | |
| Size | 84.5mm*56.3mm*27.3mm |
| Weight | 140g(0.31lb) |
| Indicators | |
| Chipsets | Ambarella H22 |
| Sensor | OV05A20 |
| Indicators | 3 color LED indicator for camera status |
| 3 color LED indicator for battery level |
| programmable buzzer |
| vibration |
| Durability | |
| Shock Proof | 1.8m (5.9ft) |
| IP Rating | IP67 |
| Video/picture/audio | |
| Coding | H.264/H.265 |
| View Angle | 140 degrees |
| Video Resolution | 1080P30 (Chipsets support 4K,limit to 1080 for lower power consumption) |
| 720P30 |
| 480P30 |
| Video Streaming Resolution | 720P30 |
| 480P30 |
| 320P30 |
| Audio Streaming | Support |
| Text Streaming | Support |
| Streaming Bitrate | 300kbs-4M kbs |
| Video Format | MP4 |
| Picture format | JPEG |
| Audio Format | AAC |
| Snap Shot | During recording |
| EIS | 6 axis image stabilizer(Optional) |
| SOS | Audio alarm activates in all cameras at same group and audio alarm in command center |
| Wireless Connections | |
| Wi-Fi | 2.4G&5G, AP/STA/P2P,Wi-Fi channel can be set by cam manager |
| Bluetooth | Remote controller,support second development |
| IR | 10 meters (2 IR LED) |
| GPS | Optional |
| NFC | Optional |
| 4G | Optional |
| Clustered Talkback(PTT) | Optional |
| Battery | |
| Recording Time | 1080P Up to 12 Hours;480P Up to 15 Hours |
| GPS and WiFi on at 480P30 12 hours and 30 minutes |
| Recording and Streaming Time | 7 to 8 hours |
| Standy Time | 100+ hours |
| Charging Time | 4 hours |
| Pre&post recording | |
| Pre-recording | 30 seconds to 1 minute varies from resolution settings |
| Post-recording | 30 seconds to 1 minute varies from resolution settings |
| Motion Detect | support |
| Security Features(Optional) | |
| File Encryption | AES256 encryption during writing files to memory card |
| Network Security | AES256 encryption RTSP Video/audio/Text streaming data |
| Wi-Fi Security | Https&Http Server |
| USB Command & JSON command | Dynamic Pin Code authentification |
| all camera settings available under mass storage mode |
| all camera settings available under USB simple mode |
| USB heart beat available |
| control over LED/buzzer available under mass storage mode |
| Ambarella driver free even while USB encryption activated |
| Support driver free connection to computer |
| Hardware Interface | |
| USB Port | support |
| Popo Pin connection | support external camera connection |
| support dock & go operation |
| Mount solution | |
| Standard mount | 360 degrees rotatable crocodile mount |
| Optional mount | MOLLE compatible mount |
| CLICKFAST Stud |
| Optional accessories | |
| External Camera | Support |
| Night Vision | Ultral low light performance & IR LED |
| Storage | Optional 32GB,64GB,128GB |
| Video Stamp | |
| Content supported | User ID/Device ID/Date/Time/Geo-tags/Logo |
Professional-Grade Highlights That Matter
Your every day operations require hardware that never lets you down. This camera highlights the capable Ambarella H22 chipset, guaranteeing steady execution indeed in high-pressure circumstances. The framework captures crystal-clear 1440P video at 30 outlines per moment, giving the detail you require for court procedures and occurrence reviews.
The progressed OV05A20 sensor conveys uncommon picture quality in different lighting conditions. Whether you're working amid shinning sunshine or challenging nighttime scenarios, the camera naturally alters to capture exact colors and sharp subtle elements. This innovation guarantees each vital minute is archived with proficient clarity.
Secure Information Assurance You Can Trust
Data security remains fundamental in law requirement operations. The AES256 encryption framework secures all recorded substance from unauthorized get to. This military-grade encryption guarantees your film remains secure all through the chain of care, keeping up its keenness for lawful proceedings.
The gadget stores information on expandable memory extending from 32GB to 256GB. With productive H.264/H.265 encoding, you can record over 24 hours of persistent film without capacity concerns. The shrewd compression innovation keeps up video quality whereas optimizing capacity space for expanded operations.
Real-Time Connectivity for Modern Policing
Your Real Time Body Camera excels in providing instant communication capabilities. The built-in 4G and WiFi modules enable live streaming directly to command centers or supervisory personnel. This feature proves invaluable during critical incidents requiring immediate oversight or backup support.
GPS positioning functionality keeps dispatch informed of your exact location. The system continuously tracks officer positions, enabling rapid response coordination and enhanced officer safety protocols. Track playback features allow supervisors to review patrol routes and incident locations comprehensively.
Built for Real-World Durability
Field operations require durable equipment.
This camera meets IP67 waterproof benchmarks and survives 2-meter drops without compromising usefulness. The 3200mAh battery guarantees all-day control, and the 2-inch HD show offers clear playback, with a screen-off mode to moderate battery amid expanded shifts.
Advanced Communication Integration
This gadget serves as a total communication center with coordinates walkie-talkie and amplifier, killing the require for different gadgets. The communication card interface underpins different modules without connectors, permitting divisions to customize network based on operational needs and foundation.
Streamlined Evidence Management
Your department benefits from streamlined evidence processing with automatic timestamps and GPS-tagging, ensuring an unbreakable chain of custody. This reduces administrative work and ensures legal compliance. Wireless direct uploads to evidence management platforms accelerate case preparation and reduce the time between incident and evidence availability for prosecutors.
Proven Global Performance
ISHOOP cameras are trusted by law enforcement in 30+ countries, meeting diverse regulatory and operational standards. Our engineering team offers full support, and the 18-month warranty exceeds industry standards, reflecting confidence in the camera's quality and manufacturing excellence.
Making the Right Choice
Your department deserves equipment that enhances officer safety while maintaining public accountability. This product combines advanced technology with practical functionality, creating a solution that works in real-world conditions.
Ready to upgrade your evidence collection capabilities? Contact our team at sales@ishoop.com.cn to discuss how the Real Time Body Camera can meet your specific operational requirements and budget considerations.
