Infrared Body Camera
Sensor: CMOS
Special Features: Waterproof / Weatherproof
Technology: Infrared
Battery: 3200mAH
Resolution: 1296P
Video Format: H.264 MPEG4
Warranty: 18 Months
Storage: 32GB/64GB/128GB/256GB
- Product Description
Infrared Body Camera: Advanced Night Vision Technology for Professional Security
When you need reliable surveillance capability that performs flawlessly in complete darkness, our Infrared Body Camera delivers uncompromising performance. This cutting-edge gadget combines progressed infrared innovation with professional-grade recording highlights, making it the idealize arrangement for law authorization, security experts, and anybody requiring crystal-clear documentation in low-light situations. Our infrared-enabled body camera guarantees you never miss basic subtle elements, whether you're watching dull boulevards or exploring faintly lit areas.
Specification
| RECORDING | |
| Main Chipset | Ambarella A7L50 |
| Sensor | 5MP CMOS sensor |
| Lens | 140 degree, wide angel F2.0 |
| Video Resolution | 2560x1080(30 FPS)/2304X1296(30 FPS)/1296.1920x1080P(30FPS)/1280x720(30FPS)/848x480(30FPS) |
| Video Format | H.264 MPEG4 |
| AES256 Encryption | Optional |
| Fast forward | 2X, 4X, 8X,16X, 32X, 64X |
| REW | 2X, 4X, 8X, 16X, 32X, 64X |
| Audio | High Quality Build-in Microphone |
| Audio Format | AAC2/MP3 |
| Water Mark | User ID, Time and date Stamp Embedded into Video |
| Camera | 36 Megapixel Camera option with optional burst shot(5/10/15/20/25 photos) |
| Camera Format | 36M, 16M, 12M, 8M, 5M |
| Snap Shot | Capture Photos During Video Recording |
| Shutter time | 1/1000-1/2 seconds |
| Infrared illumination for night | Not less than 4.5 m in total darkness |
| Car Mode | Support |
| Loop Recording | Loop recording to be switched on / off in the settings |
| Cycle Recording | Support |
| Storage Capacity | 32G/64G/128G |
| Storage Level | Visual Indicator |
| Record Led | Red |
| One Button Recording | Support One Button Record |
| Activation prompt | Audible, Visual, and Tactile Vibration Confirm Activation of Record |
| IR Light | 2 IR Lights |
| VIDEO/IMAGE REVIEW | |
| LCD Screen | 2 inch TFT-LCD High-Resolution Color Display |
| Audio Playback | Yes |
| Video Transfer | USB 2.0 |
| CAMERA | |
| Recording Angle | Wide Angle 140 degrees |
| Focus range | Standard installation of at least 1.5 m to infinity |
| Night Vision | Up to 10 Meters with Visible Face Detection |
| Waterproof | IP67 |
| Clip | High Quality Metal Clip with 360 degrees Rotation |
| Wifi | Option |
| GPS | Option, Internal GPS, GPS player to show the route of video |
| BATTERY | |
| Type | Built-in 3500mAH Lithium |
| Charging Time | 180 minutes |
| Continuous Recording | 8 Hours(720p30, LCD OFF), if power bank is connected, then no limitation |
| Low Battery Warning | Beep Alert |
| OTHERS | |
| Unique ID number/unit | Include 5 digit device ID and 6 digit police ID |
| Language | English/Chinese/Russian |
| Password Protection | To set an administrator password on the PC management software to allow deletion from PC, and modify the password in the PC management software. User can only view the videos but cannot delete it. |
| Pre-record function | 25 seconds pre-record(1080P30), 35 seconds pre-record(720p30) 1080p30, 10/20/25/off seconds 720p30, 10/20/30/35/off seconds |
| Post-record function | 10/20/30/60/120/off seconds last-record |
| Motion Detector | The ability to adjust the recording if the motion(at a distance of no more than 1m) |
| Photography during video recording | Support |
| Sound notification | Beep when starting video or stopping video, or beep sound when opening the menu; beep volume is adjustable in the menu; |
| Burst | 5/10/15/20/25 Shot burst picture taking |
| Dimension | 77 mm *57 mm *26mm (2.91″ * 1.83″ *0.93″) |
| The video recording time of 32 GB of memory | not less than 20,000 -5 megapixel photos not less than 12,000 megapixels photos -12megapixel photos video recording Not less than 8 hours and at 1920x1080p30 for video recording Not less than 11hours and 30 minutes at 1280x720p30 for video recording Not less than 11hours and 30 minutes 848x480p60 for video recording Not less than 17 hours at 848x480p30 video recording |
| Weight | 150g (GPS built-in, metal clip); 135g( without GPS and metal clip) |
| Working Temperature | 40~60 degrees Celsius |
| Storage temperature | 28~55 degrees Celsius |
| The ability to turn off the display while recording | The display can be switched on or off during recording |
| Falling from height | Resistance to fall from a height of not less than 200 cm |
| Wifi | optional |
| ACCESSORIES | |
| Standard Accessories | USB cable,USB Charger,Car charger, User Manual, Universal metal clip,driver disc |
| Option | Shoulder mount, car mount, bullet camera,mini camera, single charging dock, dock station, GPS, Fast clip, Hemlet mount etc |

Crystal Clear Night Vision Recording
Your security shouldn’t be constrained by obscurity. Infrared actuates consequently in moo light, conveying clear black-and-white film. With 1296P/60fps video, 36-megapixel pictures, and a 140-degree wide-angle focal point, you capture each detail with remarkable clarity.
The 2.0-inch LCD screen lets you survey film right away. This include demonstrates important when you require to confirm what you've recorded or share data with colleagues on the spot.
Built for Proficient Demands
Your work environment requests hardware that can handle challenging conditions. This tough camera highlights IP67 waterproofing, ensuring your speculation from rain, clean, and other natural hazards.
The 3200mAh battery conveys 10 hours of video, 11+ hours of sound, and 20 hours on standby. One-button operation permits moment video, sound, or photo capture without fueling on to begin with, giving pivotal fast reaction in emergencies.
Advanced Network Features
Modern security requires solid network. Built-in GPS logs exact area information with each recording, including basic setting for reports. WiFi empowers remote exchange and inaccessible observing, letting you share basic film rapidly without requiring coordinate gadget access.
The programmed circle recording work guarantees you never run out of capacity space. When memory comes to capacity, the framework naturally overwrites the most seasoned records with unused recordings.
Flexible Storage Options
Your storage needs vary depending on your specific requirements. Choose from multiple storage capacities:
- 32GB for basic daily operations
- 64GB for extended shifts
- 128GB for comprehensive documentation
- 256GB for maximum storage capability
All footage transfers securely via the included USB cable. This wired connection ensures your sensitive data remains protected during file transfers.

Professional Quality You Can Trust
ISHOOP brings over 10 years of digital imaging expertise to this Infrared Body Camera. Our products serve law enforcement and security professionals in more than 30 countries worldwide.
Every camera is thoroughly tried in our ISO-certified office, upheld by an 18-month guarantee for unwavering quality. The H.264 MPEG4 arrange guarantees wide compatibility, making your film effectively available on standard gadgets and computer program platforms.
Perfect for Different Applications
Law authorization employments this camera for watches and occurrence recording, whereas security watches depend on its night vision. Examiners esteem its tactful recording and long battery life, and responders advantage from its rough, instant-activation plan. The 21x computerized zoom captures removed subjects clearly for secure, successful surveillance.
Technical Excellence
The CMOS sensor gives high-quality pictures in all lighting, and infrared guarantees solid 24/7 recording. Its weatherproof construct keeps up execution in rain, snow, or extraordinary temperatures. Productive video compression jam quality whereas maximizing capacity capacity for proficient utilize.

Get Your Product Today
Don't compromise on safety and documentation quality. This professional-grade Infrared Body Camera provides the reliability, features, and performance you need for demanding security work.
Ready to experience the difference that professional infrared recording technology makes? Contact our team at sales@ishoop.com.cn for pricing information, technical specifications, or custom configuration options.
Your safety and professional success deserve equipment that performs when you need it most. Trust ISHOOP's proven expertise to deliver the advanced surveillance capabilities that make the difference in critical situations.
