Body Worn Video Camera

Product Details:
Compression: H.264 MPEG4/H.265 MPEG4
Main Chipset: Ambarella H22
Video Resolution: 1080P30, 720P30
Photo Size: 4M/8M/12M/16M/30M/40M
Pre_recording: 5sec/10sec/15sec/20sec/30sec/60sec/2Minutes
Post_recording: 5sec/10sec/15sec/20sec/30sec/60sec/2Minutes
Battery: 3400mAh
Memory: 32G/64G/128G/256G
Sensor: OS05A20

Product Description

Advanced Body Worn Video Camera - Professional Security Solution

Are you looking for a reliable Body Worn Video Camera that delivers exceptional performance in demanding environments? Our ISHOOP proficient body cameras combine cutting-edge innovation with vigorous plan to meet your security and law requirement needs. With over 10 a long time of computerized imaging involvement, we get it what things most when reporting basic circumstances and ensuring both officers and the public.

Superior Execution with Ambarella H22 Technology

Your security operations request the best innovation accessible. Our body worn cameras include the effective Ambarella H22 chipset, conveying crystal-clear video quality and solid execution in any condition. This progressed processor guarantees smooth recording whereas keeping up great battery efficiency.

Key Technical Specifications:

RECORDING
Main Chipset	Ambarella H22
Sensor	OS05A20
Lens	140 degree, wide angel F2.0
Video Resolution	2560X1440 30P / 1920X1080 60P / 1920X1080 30P / 1280X720 60P /1280X720 30P / 848X480 30P
Video Format	H.264 MP4/H.265 MP4
Fast forward	2X, 4X, 8X,16X, 32X, 64X
REW	2X, 4X, 8X, 16X, 32X, 64X
Audio	High Quality Build-in Microphone.
Audio Format	AAC
Water Mark	User ID, Time and date Stamp Embedded into Video.
Photo Burst	2/3/5/10/15/20/30 pcs
Selfie	3sec/ 5sec/ 10sec
Photo size	4M/ 8M/ 12M/ 16M/ 30M/ 40M
Photo Format	JPG
Snap Shot	Capture Photos During Video Recording
Loop Record	Loop record to be switched on / off in the settings
Pre Record	5sec/ 10sec/ 15sec/ 20sec/ 30sec/ 60sec
Post Reccord	5sec/ 10sec/ 15sec/ 20sec/ 30sec/ 60sec/ 2Minutes
Storage Capacity	32G/64G/128G
Storage Level	Visual Indicator
Record Led	Red
One Button Recording	Support One Button Record
Activation prompt	Audible, Visual, and Tactile Vibration Confirm Activation of Record
IR Light	2 IR Lights
VIDEO/IMAGE REVIEW
LCD Screen	2 inch TFT-LCD High-Resolution Color Display
Audio Playback	Yes
Video Transfer	USB 2.0
CAMERA
Recording Angle	Wide Angle 140 degrees
Night Vision	Up to 10 Meters with Visible Face Detection
Waterproof	IP67
Clip	High Quality Metal Clip with 360 degrees Rotation
Wi-Fi	2.4G&5G, AP/STA/P2P,Wi-Fi channel can be set by cam manage
GPS	Internal GPS, GPS player to show the route of video;
BATTERY
Recording Time	1080P Up to 12 Hours; 480P Up to 15 Hours; GPS and Wi-Fi on at 480P30 12 hours and 30 minutes
Recording and Streaming Time	7 to 8 hours (432x240 @25fps, bitrate 1000Kbps)
Standy Time	100+ hours
Charging Time	4hours
OTHERS
Unique ID number/unit	Include 6 digit device ID and 6 digit police ID
Language	English/Chinese
Password Protection	To set an administrator password on the PC management software to allow deletion from PC, and modify the password in the PC management software.
Motion Detector	The ability to adjust the recording if the motion.
Sound notification	Beep when starting video or stopping video, or beep sound when opening the menu; beep volume is adjustable in the menu;
Dimension	77 mm 57 mm 26mm (2.91” * 1.83” *0.93”)
Pre-recording	30 seconds to 1 minute varies from resolution settings
Post-recording	30 seconds to 1 minute varies from resolution settings
The ability to turn off the display while recording	The display can be switched on or off during recording
Falling from height	Resistance to fall from a height of not less than 200 cm
Wifi	Support STA mode
Steaming Resolution	1280x720/ 848x480/ 432x240
Steaming Frame Rate	5FPS/ 10FPS/ 15FPS/ 20FPS/ 25FPS/ 30FPS
Streaming Bitrate	300 Kbps/ 500 Kbps/ 1000 Kbps/ 2000 Kbps/ 3000 Kbps/ 4000 Kbps/ 5000 Kbps
Live stream Monitor Platform	Support h265 streaming Multi-cameras video Monitor, Position display, intercom, PTT, and etc.
Cam manager	Wi-Fi SSID/Password, end point IP, device ID etc, include general settings.
PTT	Support talk from camera with the control room(officers)
SOS	Support send message to control room；
Video Stamp	Content support User ID/Device ID/Date/Time/Geo-tags/Logo
Bluetooth	Support Heartbeat Rate activate recording, Remote controller
EIS	6 axis image stabilizer(Optional)
Mini Camera	Support
Security Features (Optional)
File Encryption	AES256 encryption during writing files to memory card AES256 encryption RTSP Video/audio/Text streaming data
Network Security	Https& Http Server
Wi-Fi Security	Dynamic Pin Code authentification
USB Command & JSON command
	all camera settings available under mass storage mode all camera settings available under USB simple mode USB heart beat available control over LED/buzzer available under mass storage mode Ambarella driver free even while USB encryption activated Support driver free connection to computer

security guard body cameras

Advanced Security Features You Can Trust

Security professionals need equipment they can rely on. Our Body Worn Video Camera includes enterprise-grade AES256 encryption to protect your recorded data from unauthorized access. This military-level security ensures your evidence remains tamper-proof and legally admissible.

Professional Features Include:

Pre-recording: Capture 5 seconds to 2 minutes before activation
Post-recording: Continue recording 5 seconds to 2 minutes after stopping
Live Streaming: Real-time video transmission capabilities
GPS Positioning: Accurate location tracking for incident documentation
SOS Emergency Function: One-touch emergency alert system
WIFI Connectivity: Wireless data transfer and remote management

Built for Demanding Environments

Designed for law enforcement and security professionals, our cameras withstand tough conditions with IP67 waterproof and IK09 impact resistance. Lightweight and compact, they won’t hinder your duties. The flexible mounting system allows discreet or visible placement, adapting seamlessly to routine patrols or emergency responses while maintaining reliable performance in any workflow.

Smart Recording Technology

Capture every critical moment with intelligent pre- and post-recording features, ensuring complete incident documentation. The OS05A20 sensor provides exceptional low-light performance, while high-resolution photo capability delivers detailed still images for accurate documentation in any lighting condition.

Global Quality Standards

Our manufacturing facility operates under strict ISO international quality systems. Every unit undergoes comprehensive testing to ensure reliability in the field. We're trusted by law enforcement agencies across more than 30 countries worldwide.

Quality Certifications:

CE European Conformity
IP67 Waterproof Rating
IK09 Impact Resistance
ISO Quality Management Systems

Certification of body cameras

Comprehensive Support and Service

When you choose our Body Worn Video Camera, you're getting more than just equipment. Our professional engineering team provides ongoing technical support throughout your camera's lifecycle. Every unit includes a comprehensive 1-year warranty for your peace of mind.

We offer customization alternatives to meet particular operational necessities. Our OEM/ODM administrations can adjust highlights, lodging plan, and program interfacing to coordinate your organization's needs.

Why Select ISHOOP Body Worn Cameras?

With about a decade of involvement in advanced imaging innovation, we get it the interesting challenges confronting security experts. Our cameras are planned by experts for experts, combining unwavering quality, execution, and ease of use.

We serve clients around the world with quick, dependable shipping through DHL, UPS, and other premium carriers. Our worldwide bolster organize guarantees you get incite help wherever your operations take you.

Ready to upgrade your security documentation capabilities? Contact our team at sales@ishoop.com.cn to discuss your specific requirements. We'll help you select the perfect configuration and provide detailed technical specifications for your evaluation.

Your safety and success matter to us. Let our advanced Body Worn Video Camera technology help you document the truth and protect what matters most.
